Class 12 Biology Chapter 11 Notes: Biotechnology – Principles And Processes
Biology studies living organisms and includes their morphology, physiology, anatomy and origin. The concept of biotechnology is based on Biology. Biotechnology harnesses cellular processes to enhance the quality of products that help improve our lives.
Biotechnology involves using living organisms, cells or enzymes in large-scale manufacturing. Promoting products and processes using modern biotechnology and Genetically Modified Organisms was made possible only when human beings mastered ways to alter DNA. This fundamental process is called Genetic engineering.
Extramarks is the preferred online learning partner for lakhs of students preparing for Class 11 and Class 12 Biology subjects. Our team of academic experts have created study materials based on the latest CBSE syllabus and NCERT guidelines. Students can confidently rely on our study solutions.
Extramarks Class 12 Biology Chapter 11 Notes covers all the fundamental points of Biotechnology to assist students in understanding the importance of genetic engineering in health sciences and technology.
Key Topics In Class 12 Biology Chapter 11 Notes
Below are the important topics covered in our Class 12 Biology Chapter 11 Notes.
- Principles of Biotechnology.
- Tools of Recombinant DNA Technology.
- Processes of Recombinant DNA Technology.
Principles Of Biotechnology
Class 12 Biology Chapter 11 Notes starts by explaining the two key strategies that introduced the creation of modern biotechnology:
(i) Genetic engineering:
The methods to alter the chemistry of the genetic material (DNA & RNA) to introduce genes into host species and thus alter the phenotype of the host organism.
(ii) Bioprocess engineering:
This process involves the maintenance of a sterile atmosphere in chemical engineering processes to allow the growth of only the desired microbes in significant quantities to manufacture biotechnological products like antibiotics, vaccines, etc.
Recombinant DNA:
- Traditional hybridisation procedures often lead to the multiplication of both unwanted and desired genes. At the same time, the new strategies of recombinant DNA technology have brought a breakthrough in this limitation with the help of gene cloning and gene transfer.
- Recombinant DNA technology introduces only the desired genes without adding undesirable genes to the target organism.
- DNA will only multiply in the progeny cells when incorporated into the recipient’s genome and inherited with the host DNA. The alien piece of DNA becomes part of a chromosome capable of replication.
- A specific DNA sequence in a chromosome responsible for starting replication is called the ‘Origin of Replication’.
- To multiply a foreign piece of DNA in an organism, it needs to be a part of a chromosome with the ‘Origin of Replication’. The ori permits the foreign piece of DNA to replicate and multiply in the host organism by a process called cloning.
This section is further detailed in our Class 12 Biology Chapter 11 Notes. Students can access the chapter notes from Extramarks’ website.
The construction of the first recombinant DNA:
- The first artificial recombinant DNA emerged from the potential of linking a gene encoded antibiotic resistance with a plasmid of Salmonella typhimurium. Stanley Cohen and Herbert Boyer achieved this by isolating the antibiotic resistance gene in 1972. They cut out a piece of DNA from a plasmid responsible for contributing to antibiotic resistance.
- Restriction enzymes cut the DNA at specific locations and link the cut piece of DNA with the plasmid DNA. These plasmid DNA behave as vectors to transfer the piece of DNA adhered to it.
- With the aid of the enzyme DNA ligase, the antibiotic resistance gene was linked with the plasmid vector.
- The new combination of circular autonomously replicating DNA created in vitro is called recombinant DNA.
- When this DNA is transferred into Escherichia coli, it could replicate using the new host’s DNA polymerase enzyme and produce multiple copies.
- The cloning of antibiotic resistance genes in Escherichia coli was the ability to multiply copies of antibiotic resistance genes.
The three basic steps in genetically modifying an organism:
- Identification of DNA that comprises suitable genes
- Desirable DNA is introduced into the host organism.
- After maintaining introduced DNA in the host organism, the DNA is transferred to its progeny.
Students are recommended to register on Extramarks website and get full access to our Class 12 Biology Chapter 11 Notes. The study notes are specially prepared for students to gain a fundamental knowledge of the essential principles of Biotechnology.
Tools of Recombinant DNA Technology :
The critical tools that are involved in genetic engineering:
- Restriction enzymes
- Polymerase enzymes
- Ligases
- Vectors
- Host organism
Restriction Enzymes:
- Two enzymes in Escherichia coli were isolated. They were responsible for restricting the growth of bacteriophages. One of these added methyl groups to DNA while the other cut DNA. This was known as restriction endonuclease.
- Hind II was the first restriction of the endonuclease. Its functioning depended on a specific DNA nucleotide sequence that was isolated and characterised after five years.
- Hind II cut DNA molecules at specific points by recognising a specific sequence of six base pairs. This specific base sequence is termed the recognition sequence for Hind II.
- However, today, over 900 restriction enzymes have been secluded from more than 230 strains of bacteria, each of which recognises various recognition sequences.
- While naming these enzymes, the first letter of the name is from the genus. The second two letters are derived from the species of the prokaryotic cell from which they were isolated.
For Example, EcoRI (Escherichia coli RY 13).
- The letter ‘R’ is derived from the strain’s name. Roman numbers that follow the names indicate the order of isolation of the enzymes from that strain of bacteria.
- Restriction enzymes belong to a larger class of enzymes called nucleases.
These are of two kinds:
- Exonucleases: get rid of nucleotides from the ends of the DNA.
- Endonucleases: make cuts at certain positions within the DNA.
- A restriction endonuclease operates by ‘inspecting’ the length of a DNA sequence. Once the specific recognition sequence is found, it will combine with the DNA.
- Then each of the two strands of the double helix is cut at distinct points in their sugar-phosphate backbones.
- Each restriction endonuclease will distinguish specific palindromic nucleotide sequences in the DNA.
The process of Restriction Enzymes is further explained in our Class 12 Biology Chapter 11 Notes. Students who are looking for easy guided solutions for learning the chapter of Biotechnology should register on Extramarks and get our study notes.
What are Palindromes?
Palindromes are groups of letters that form the exact words when read both forward and backward, e.g., MALAYALAM. The palindrome in DNA is a sequence of base pairs. It reads the same on the two strands when the orientation of the reading is kept the same.
For Example, the following sequences are read-alike on the two strands in the 5′ to 3′ direction. This is also true if the arrangement is read in the 3′ to 5′ direction.
5′ —— GAATTC —— 3′
3′ —— CTTAAG —— 5′
Restriction enzymes cut up the DNA strand between the same two bases on the opposite strand and a little away from the centre of the palindrome sites. This leaves portions of single-stranded DNA at the ends. Overhanging stretches called sticky ends, present on each strand, form hydrogen bonds with complementary cut counterparts. This stickiness of the ends enables the action of the enzyme DNA ligase.
In genetic engineering, ‘recombinant’ molecules of DNA are formed with the help of restriction endonucleases composed of different DNA genomes. When the same restriction enzyme cuts the DNA, the DNA fragments formed have the same kind of ‘sticky-ends’. These are joined together using DNA ligases.
Students will get more detailed information about the importance of restriction enzymes in genetic engineering in our Class 12 Biology Chapter 11 Notes.
Separation and isolation of DNA fragments:
After cutting DNA by a restriction endonuclease, the fragments get separated by gel electrophoresis. DNA fragments being negatively charged molecules are separated by moving towards the anode in the presence of an electric field through a medium. The most commonly used medium is agarose gel (a natural polymer) extracted from seaweeds. The separation of DNA fragments is based on their size through the sieving effect given by the agarose gel. Thus, the smaller fragments move farther on the agarose gel.
The separated DNA fragments can be seen only after staining the DNA. A compound, ethidium bromide, is used for visualisation, followed by exposure to UV radiation. You will observe bright orange-coloured bands of DNA when exposed to UV light. The separated DNA bands are extracted from the gel piece after being cut. This process is called elution. The purified DNA fragments are used to construct recombinant DNA by joining them with cloning vectors.
Cloning Vectors:
- Because of their more significant number per cell, Bacteriophages have large copy numbers of their genome within the bacterial cells.
- Some plasmids only consist of one or two copies per cell, while others may have 15-100 copies per cell.
- Multiplication of equal numbers to the copy number of the plasmid becomes easy with the ability to link an alien piece of DNA.
- Vectors are engineered to help the easy linking of foreign DNA and the selection of recombinants from non-recombinants.
Following features are required to facilitate cloning into a vector:
- Origin of replication (ori): ori is a sequence from where replication begins. Any piece of DNA linked to this sequence, further replicates within the cells of a host. This sequence is also responsible for controlling the copy number of the linked DNA. Thus, if anyone wants to retrieve a large number of copies of the target DNA, it should be cloned in a vector whose origin supports a high copy number.
- Selectable marker: Apart from ‘ori’, the vector requires a selectable marker. The selectable marker assists in the identification and elimination of non-transformants. Also, it selectively allows the growth of the transformants. Transformation is the procedure through which a piece of DNA is introduced into a host bacterium. The genes encode antibiotic resistance. These include ampicillin, chloramphenicol, tetracycline or kanamycin, etc., which are useful selectable markers for E. coli.
- Cloning sites: The vector requires very few single recognition sites for the restriction enzymes to link foreign DNA. The availability of recognition sites within the vector will produce numerous fragments, which will cause complications in gene cloning.
The ligation of foreign DNA is carried out at a restriction site that occurs in one of the two antibiotic resistance genes. For instance, you can ligate an alien DNA at the BamH I site of the tetracycline resistance gene in the vector pBR322.
The transformants growing on an ampicillin containing matrix are then transported on a tetracycline matrix. The recombinants will multiply in an ampicillin containing matrix but not on that containing tetracycline. Non- recombinants will grow on the medium with both antibiotics. In this case, only one antibiotic resistance gene helps select the transformants. In contrast, the other antibiotic resistance gene gets ‘inactivated due to insertion’ of foreign DNA and helps choose recombinants.
- Vectors for cloning genes in plants and animals: The methods of transferring genes into plants and animals extracted from bacteria and viruses have been known for ages. For instance, Agrobacterium tumefaciens is a pathogen of various dicot plants which can deliver a piece of DNA known as ‘T-DNA’. T-DNA converts normal plant cells into a tumour and directs these tumour cells to produce the chemicals required by the pathogen. In the same way, retroviruses in animals can transform normal cells into cancerous cells.
The tumour-inducing (Ti) plasmid of Agrobacterium tumefacient has now been modified into a cloning vector that is not pathogenic to the plants but can still use the mechanisms to deliver desired genes into a variety of plants.
These four features to facilitate the cloning of vectors are covered at length in our Class 12 Biology Chapter 11 Notes. Extramarks study notes are prepared by Biology teachers with decades of experience, hence making the quality of content extremely good.
Competent Host:
- DNA is a hydrophilic molecule. Thus, it cannot pass through cell membranes. In contrast, bacterial cells are made ‘competent’ to accept plasmid DNA.
- The bacteria are treated with a specific divalent cation concentration, such as calcium. Calcium raises the efficiency with which DNA enters the bacterium through the pores of the cell wall.
- Recombinant DNA is forced into such cells by incubating the cells with recombinant DNA on ice.
- After that, the cells are placed shortly at 42 degrees celsius to give heat shock and then put back on ice. This allows the bacteria to take up the recombinant DNA.
- Another way to introduce foreign DNA into a host cell is through micro-injection. Recombinant DNA is injected directly into the nucleus of an animal cell.
- Another method appropriate for plant cells is bombardment with high-velocity micro-particles of gold or tungsten coated with DNA. This procedure is known as biolistics or gene gun.
- The last method uses ‘disarmed pathogen’ vectors. The vectors transport the recombinant DNA into the host cell when allowed to infect the cell.
Processes Of Recombinant DNA Technology
The process is explained in detail in our Class 12 Biology Chapter 11 Notes. Below are the summary points highlighting the key steps in Recombinant DA technology:
Isolation of DNA:
- DNA and other macro_molecules such as RNA proteins and lipids are enclosed within the cell membrane.
- The cell is treated with enzymes such as lysozyme(bacteria), cellulase(plant cells) and Chitinase(fungus) that isolate the DNA.
- The treatment with ribbon nucleus proteins can extract RNA through the treatment with proteins.
- DNA finally precipitates upon adding chill ethanol in a suspension of fine threads.
Cutting of DNA at Specific Locations:
- Restriction enzyme digestion is performed by incubating purified DNA molecules with the restriction enzyme.
- The specific enzymes require optimum conditions.
- DNA is negatively charged and moves towards the anode when the Agarose gel electrophoresis is employed.
- The process is repeated with vector DNA as well.
- The cut source of DNA, the vector DNA with a specific restriction enzyme, the cut-out gene of interest and the cut vector with space are mixed, followed by the addition of ligase.
- By this Recombinant DNA is prepared.
Amplification of Gene of Interest using PCR:
- In Polymerase Chain Reaction(PCR), multiple copies of DNA of interest are synthesised in vitro with the help of two sets of primers; chemically synthesied oligonucleaotides and theDNA polymerase enzyme.
- DNA polymerase enzymes extend the primers utilising nucleotides provided in the reaction and the genomic DNA as template.
- When the DNA replication is repeated many times, this segment of DNA can be amplified to construct a billion copies.
- Thermostable DNA polymerase achieves repeated amplification and remains active during high temperature-induced denaturation of double standard DNA.
- Amplified fragments can be used for ligation with a vector to continue cloning.
Each cycle has three steps:
(i) Denaturation;
(ii) Primer annealing
(iii) Extension of primers
Insertion of Recombinant DNA into the Host Cell:
- Competent recipient cells take up DNA present in their surroundings.
- If recombinant DNA consists of a gene for resistance to an antibiotic is transferred into E.coli cells , the host cells transform into ampicillin-resistant cells.
- Only transformants will grow if they are spread on agar plates containing ampicillin, while untransformed recipient cells will die.
- The presence of the ampicillin resistance gene allows the selection of the desired transformed cell.
- The ampicillin resistance gene is called a selectable marker.
Obtaining the Foreign Gene Product:
- The ultimate aim is to produce a desirable protein.
- Knowledge of many technical details is essential when the expression of foreign genes in host cells is involved.
- The cloned gene of interest is optimised to induce the expense expression of the protein. This production is taken on a large scale.
- A recombinant protein is expressed in a heterologous host.
- Cells with the cloned gene of interest are grown in a lab for small-scale production.
- The cultures extract the required protein and then purify it using different separation techniques.
- With the help of a continuous culture system, the cells are multiplied where the used medium is drained out, and the fresh medium is added to maintain the exponential phase. This culture method produces larger biomass, which yields a more significant number of desired proteins.
What are Bioreactors?
As defined in our Class 12 Biology Chapter 11 Notes, Bioreactors are vessels where raw materials are biologically converted into specific products using microbes. A bioreactor processes large volumes of culture. The advantage of bioreactors is that it provides suitable growth conditions for achieving the desired product, such as optimum temperature, PH vitamins, etc.
Class 12 Biology Notes Chapter 11 emphasises the need for bioreactors for large scale production. A commonly used stirred tank bioreactor is in the shape of a cylinder with a curve base. It facilitates mixing with the help of a stirrer and allows the availability of oxygen throughout the bioreactor. The air can be bubbled into the reactor. Stirred tank reactor consists of an oxygen delivery system, a foam control system, a temperature control system, a pH control system, and sampling ports for small volumes of culture to be withdrawn.
(b) Sparged stirred-tank bioreactor through which sterile air bubbles are sparged
Downstream Processing:
Before marketing a finished product, it must be subjected to several processes. The processes are:
- Separation and Purification(Collectively referred to as Downstream processing).
- Formulation with suitable preservatives. In the case of drugs, the Formulation has to undergo a full clinical trial.
- Proper quality control testing for each product is mandatory.
- The downstream processing and quality control are different for every product.
